Product Description
Discontinued Model
Electrocorder CT-7VAR
- Type: Three Phase Voltage & Current Logger + Power Factor on a single phase.
- Measurements: V, A, PF.
- Calculations: kW, kWh, kVAR, kVA.
- Inputs:
- Voltage - 0V to 500Vrms (Ph – Ph) or 0V to 300Vrms (Ph – N).
- Current - Two models, 1–60 Amps & 4–400 Amps.
- Maximum cable diameter is 30mm.
- Sampling rate: Continuous, 16 samples per cycle 800Hz @ 50Hz.
- Logging rate: 2 sec to 1 hr.
- Memory: 10 mins gives 50 days logging, 1 hr gives up to 300 days logging.
- PC Connection: USB.
- Data transfer: Direct to PC via USB cable.
- Power: Line powered from mains (can be battery powered for 1 week).
- Software: Software included.
CT-7VAR Technical Specifications Download
