Product Description
Discontinued Model
Electrocorder EC-3V
- Type: Three Phase Voltage Logger.
- Measurements/Calculations: Voltage.
- Inputs:
- Voltage - 30V to 300VAC (Ph – N).
- Sampling rate: Continuous, 16 samples per cycle 800Hz @ 50Hz.
- Logging rate: 1 sec to 1 hr.
- Memory: 10 min gives 50 days logging, 1 hr gives up to 300 days logging.
- PC Connection: USB.
- Data transfer: Direct to PC via USB cable.
- Power: Mains powered.
- Software: Software included.
EC-3V Technical Specifications Download
